Prepress CTP Printing Plate DOT Detecting Equipment Densitometer
Brief Introduction
Dot mainly expresses hue and gradation in printing industry. They are foundation of copy and color reproduction of printed products.
Dot, tiniest unit to adsorb ink in offset print, reflects hue, gradation and tone of source products in printed.
Changes of dots results in problems of printed products including sharpness, gradation, hue, contrast, tone of printing ink, ink density and black overprint.
The advanced dot measurement technology is used for detecting and controlling plate and quality of dot. It supports all kinds of screening technologies used at present including amplitude screening, frequency modulation screening, specialized screening and hybrid screening technology.
Specification
Model
ECOO Densitometer
Magnification
5-200
Screen
720P HD LCD touchable screen
Operation system
Android 5.0
Digital zoom
2
Image format
BMP
Net weight
300g
Set weight
500g
Image size
1280*720
Lighting White light
LTD*8pcs
Measuring time
1 s
Repeatability
±0.02 D(density), ±1%(dot area)
Interface Micro
USB 2.0, HDMI
Storage
16GB
ROM
2GB
Battery capability
3200mAh
Battery type
Rechargeable lithium battery
Network
WIFI
Dimension
185*70*55 mm
Sensor
CMSO 1.3 megapixel
| Model | Ecoo Densitometer |
| Magnification | 5-200 |
| Screen | 720 P HD LCD touchable screen |
| Operation system | Android 5.0 |
| Digital zoom | 2 |
| Image format | BMP |
| Net weight | 300g |
| Set weight | 500g |
| Image size | 1280*720 |
| Lighting | White Light LTD* 8pcs |
| Measuring time | 1 s |
| Repeatability | ±0 .02 D(density),± 1%(dot area) |
| Interface | Micro USB 2 .0 , HDMI |
| Storage | 16GB |
| ROM | 2GB |
| Battery capability | 3200mAh |
| Battery type | Rechargeable lithium battery |
| Network | WIFI |
| Dimension | 185*70*55 mm |
| Sensor | CMSO 1 . 3 megapixel |
Features
1. Android system, with photo taking, data measuring & saving, wifi connection functions;
2. 720P high resolution touch-screen can represent print image dots clearly;
3. Auto-focusing camera can easily realize two different scopes magnifying representation;
4. Advanced image processing technology, ensures the data measurement accuracy;
5. Eight built-in measurement tools can fulfill not only dot percentage and image screening measuring, but also measure length, angle, area, etc.
Producing and Packing
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
FAQ
1. Do you have other accompanying products for some end users?
Yes, we offer full range of prepress and postpress products for offest printing, including CTP/CTcP plates at most favourite price. In addition, blanket, ink, developer, processors, cutting machine and binding machines..
2. What is your normal Payment term?
100% in advance by TT.
3. What is the Lead Time?
Usually 7-10 days, and we will try our best to meet your demands.
