3 Ply Offset Compressible Rubber Printing Blanket

Brand Name : EcooGraphix

Model Number : ECOO-BL-E

Certification : ISO9000, CE

Place of Origin : China

MOQ : 50 Square Meters

Payment Terms : L/C, T/T

Supply Ability : 300,000 Sqm/Year

Delivery Time : 30 Days

Packaging Details : Standard Export Packing

Price : Negotiable

Blanket Type : Offset printing blanket

Roughness : 0.9-1.1 μm

Compressible Layer : Microspheres

Hardness : 76-80 Shore A

Color : Blue

Surface : Micro-ground and polished

Elongation : ≤ 1.2%

Tensile Strength : ≥ 80

Contact Now



 High Cost-effective Offset Compressible Rubber Printing Blanket










 ☄​ Application


EcooGraphix Printing Blanket is suitable for printing of coated papers, carton boards and the like.
So the finish products of whole offset printing would be carton, coated paper, newspaper, magazine and so on.







 ☄​ Specification


Model
ECOO-BL-E

Construction
3 ply

Thickness
1.97/1.70 ± 0.02mm

Color
Blue

Compressible
Microspheres

Surface
Micro-ground and polished

Roughness
0.9 - 1.1μm

Hardness
76 - 80

Elongation
≤ 1.2%

Tensile Strength
≥ 80

Application
Strong universality
Prefer to package print
Speed about 9000 prints/hour

Characteristic
Moderate compressible avoids moving image of machine and reduces the edge marking.
Wide-ranging print.
Prefer to carton print and full mold print
​
Model ECOO-BL-E
Construction 3 ply
Thickness 1.97/1.70 ± 0.02mm
Color Blue
Compressible Microspheres
Surface Micro-ground and polished
Roughness 0.9 - 1.1μm
Hardness 76 - 80
Elongation ≤ 1.2%
Tensile Strength ≥ 80
Application Strong universality
Prefer to package print
Speed about 9000 prints/hour
Characteristic Moderate compressible avoids moving image of machine and reduces the edge marking. Wide-ranging print. Prefer to carton print and full mold print.











​​ ☄ Structure





3 Ply Offset Compressible Rubber Printing Blanket

The printing blanket normally includes 3 layers as above:

A: a base non-woven fabric or a spun bonded non-woven fabric layer which is assigned to the printing cylinder;

B: a soft, highly resilient void-free compressible intermediate rubber layer which has closed gas pores;

C: an outer-lying void-free layer of an elastomeric layer which faces toward the printing material.










​ ☄ Characteristic





3 Ply Offset Compressible Rubber Printing Blanket



♥  High cost-effective. Our most economic blanket model as well as most popular seller. Could satisfy 85% printing jobs.

♠  High compressive ability, which allows many types and printing material in different thickness.

♦  Wide range printing, prefer package printing on carton in moderate speed.

♣  Be excellent in the action of absorbing a shock such as a mechanical impact.

♥  Prevent the material to be printed from winding around the blanket cylinder.











​​ ☄ Producing And Packaging





From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.



3 Ply Offset Compressible Rubber Printing Blanket



3 Ply Offset Compressible Rubber Printing Blanket

Blanket In Roll



3 Ply Offset Compressible Rubber Printing Blanket

Blanket In Sheet



3 Ply Offset Compressible Rubber Printing Blanket



Aluminum Bar



We can offer blanket with or without bar, depending on customers' inquiry.


$5 for each pair of bars.


Please let us know the machine model or bar size if you need blanket with bars.



3 Ply Offset Compressible Rubber Printing Blanket



3 Ply Offset Compressible Rubber Printing Blanket



3 Ply Offset Compressible Rubber Printing Blanket



Maintenance


Clean the blanket with fast volatile organic solvents.

Clean rolls when ink color changing or refilling.

Release the blanket off the cylinder when the printing machine stopped for a long time.

New blankets should be stored in dry and cool place covered with dark layer.











​ ☄ Certificates





3 Ply Offset Compressible Rubber Printing Blanket



3 Ply Offset Compressible Rubber Printing Blanket













​ ☄ FAQ

​





Q1: Do you offer free sample ? How long is the sample time of the shipping ? Does the sample fee can be returned ?



A: Since blanket is high value, we did not offer free sample. But we can offer favorable discount. It will take 5 days to prepare sample. If you place formal bulk order, we will refund the sample fee and courier cost.






Q2: About the sample what is the cost of transportation ?



A: The freight depends on weight, packing size and your country or province region, etc.






Q3: How long can I expect to get the sample ?



A: The sample will be ready for delivery in 3-5 days and will be sent via international express such as DHL, UPS, TNT, FEDEX and would be arrived within 3-5 days.






Q4: Where is your factory ?


A: Our factory is located in Hangzhou city, which is about 1.5 hours by train from Shanghai.


You are warmly welcome to visit our factory!



​
